FA PHOENIX VTOL UAV
TECHNICAL SPECIFICATIONS
DIMENSIONS
Wingspan
Length
Wing area
Flightcase dimensions
Payload bay
440 cm
120 cm
1.829 sq.m.
220 x 90 x 100 cm
30 x 18 x 12 cm
WEIGHTS & PAYLOAD
Empty weight
Empty weight including battery
Maximum takeoff weight
Payload capacity
4.1 Kg
5.7 Kg
7.2 Kg
1.5 Kg
FLIGHT CHARACTERISTICS WITHOUT PAYLOAD
Cruise speed
Maximum speed
Stall speed
Maximum flight time
Range through air
20 m/s (72 Km/h)
30 m/s (108 Km/h)
14 m/s (50 Km/h)
2 hours
130 km
FLIGHT CHARACTERISTICS WITH 1 KG PAYLOAD
Cruise speed
Maximum speed
Stall speed
Maximum flight time
Range through air
18 m/s (65 Km/h)
27 m/s (97 Km/h)
15 m/s (54 Km/h)
1 hour 50 minutes
100 km
FLIGHT CHARACTERISTICS WITH AUXILARY LiPo
Payload capacity
Maximum flight time
Range through air
600 g
2 hour 55 minutes
180 km
POWER
Battery type
Battery cells
Battery capacity
LiPo
4s
27Ah
TOLERANCES
Max takeoff/landing wind
Max wind in cruise flight
Max precipitation
Operating temperature
Absolute ceiling
11 m/s (40 Km/h)
16 m/s (57 Km/h)
Drizzle
Between -20 and +45 Celsius
14.000ft (4300m)
CAMERA
Resolution
Capture Rate
Aspect ratio
HDMI
100 MP
3 fps
4:3
1920 x 1080 @60p
* A fully autonomous, commercial-grade, VTOL drone with smart technology that has various applications. A fully autonomous, commercial-grade, VTOL drone with smart technology that has various applications. A fully autonomous, commercial-grade, VTOL drone with smart technology that has various applications.
